Description
EQUIPMENT OVERVIEW
| Item #: | AES-GIL1500 |
| Condition: | NEW |
| Year: | 2025 |
| Manufacturer: | GILLETTE |
| Model: | SP-1500-3 |
| Fuel Type: | NATURAL GAS, PROPANE |
| Hours: | NEW – 0 HOURS |
| KW: | 150 KW |
| Amperage: | 521 Amps @ 208V / 225 Amps @ 480V |
| Application: | STANDBY, STATIONARY |
| Duty: | STANDBY |
| RPM: | 1800 RPM |
| Voltage: | Multiple Voltage Options |
| Serial #: | TBD |
| Emissions Rating: |
EPA 40CFR Part 60, 1048, 1054, 1065, 1068 |
ADDITIONAL COMPONENTS
- RATINGS ARE FOR NATURAL GAS FUEL – PROPANE RATINGS WILL DIFFER
- 3 PHASE VOLTAGE OPTIONS
- 120/208V
- 120/240V
- 277/480V
- 346/600V
- GENERATOR END INFORMATION
- STAMFORD GENERATOR END
- CLASS H INSULATION
- 120 DEGREE (C) TEMP RISE
- SINGLE BEARING
- 24 MONTH WARRANTY FROM DATE OF STARTUP OR 1000 HRS OPERATION
- ENGINE INFORMATION
- PSI (POWER SOLUTIONS INTERNATIONAL) 8.8L ENGINE
- TURBOCHARGED / CHARGED AIR COOLED
- 10.1:1 COMPRESSION RATIO
- STANDARD AIR CLEANER
- 1800 RPM ENGINE SPEED
- 259 HP NATURAL GAS RATING
- 12 MONTH WARRANTY FROM DATE OF STARTUP OR 2000 HRS OPERATION
- FUEL SYSTEM
- FUEL PRESSURE (kpa) IN H20: (1.74-2.74), 7″-11″
- FUEL SUPPLY INLET LINE 1-1/4″
- SEE SPEC SHEET FOR SUEL CONSUMPTION DETAILS
- OTHER FEATURES / INCLUDED EQUIPMENT
- LEVEL 2 SOUND ATTENUATED ENCLOSURE
- INTERNAL EXHAUST SILENCER
- MAIN LINE CIRCUIT BREAKER
- FLEXIBLE OIL AND RADIATOR DRAIN HOSES
- DEEP SEA 7420 MKII DIGITAL CONTROL PANEL
- S-10B FUEL LINES GROUP
- 1-1/4″ FLEXIBLE DRY FUEL LINE
- LPG OR NATURAL GAS LINE WITH 1-1/4″ NPT FITTINGS, 16″ LONG
- S-13D 1500W ENGINE COOLANT HEATER
- COOLANT HEATER WITH ON-OFF THERMOSTAT
- S-B750 BATTERY PACKAGE
- 750 CCA STARTING BATTERY 12VDC
- BATTERY RACK AND CABLES
- AUTO START/STOP
- 12V “FLOAT” BATTERY CHARGER
- AUTOMATIC VOLTAGE REGULATION
- 12V ELECTRONIC IGNITION SYSTEM
- 12V BATTERY CHARGING ALTERNATOR
- ELECTRONIC ENGINE GOVERNOR
SHIPPING INFORMATION
| Weight | 3695 lbs |
|---|---|
| Dimensions | 134 × 48 × 73 in |
| Condition | |
| Manufacturer | GILLETTE |
| KW Rating | |
| Duty | |
| Fuel Type | |
| Application | STANDBY, STATIONARY |
